STEERING PUMP AND COLUMN BRACKET ASSEMBLY

STEERING PUMP AND COLUMN BRACKET ASSEMBLY

SUITABLE FOR YALE

REFERENCE FOR STEERING COLUMN: CS135ASE1A

REFERENCE FOR STEERING VALVE: RU074X000V2A

Type of Orbitrol
                   :                   A

    Total Length L1:           144,30 mm

    Width B        :           105,00 mm

    Height H       :           124,00 mm

    Diameter D1    :            86,00 mm

    Lenght L2      :             9,00 mm

    Nber of Splines Ac
                   :                  12

    Diameter D2    :            17,60 mm

    Number of Terminals
                   :                   3

    Diameter D3    :             8,00 mm

    Type of Thread Ta1
                   :          1 1/16 UNF

    Metric Pitch Pm1
                   :             0,00 mm

    Imperial Pitch Pi1
                   :                  12

    Type of Thread Ta2
                   :

    Metric Pitch Pm2
                   :             0,00 mm

    Imperial Pitch Pi2
                   :                   0

    Type of Thread Ta3
                   :

    Metric Pitch Pm3
                   :             0,00 mm

    Imperial Pitch Pi3
                   :                   0

    Type of Thread Ta4
                   :            7/16 UNF

    Metric Pitch Pm4
                   :             0,00 mm

    Imperial Pitch Pi4
                   :                  20

    Dist. Between Center
                   :            58,00 mm

    Type of Thread Ta5
                   :

    Metric Pitch Pm5
                   :             0,00 mm

    Imperial Pitch Pi5
                   :                   0

    Brand          :       SAUER DANFOSS
